Telegärtner H02082A0004 Καλώδιο Patch οπτικών ινών LC-Duplex σε LC-Duplex Multimode OM4 4 ίνες 100 m Aqua LSZH

The Telegärtner H02082A0004 is a high-performance fiber optic patch cable designed for reliable data transmission in demanding network environments. This 100-meter cable features LC-Duplex connectors on both ends and contains 4 multimode OM4 fibers, making it ideal for high-bandwidth applications such as data centers, enterprise networks, and telecommunications infrastructure. The cable is constructed with a Low Smoke Zero Halogen (LSZH) jacket in aqua color, ensuring safety and easy identification.

Advantages

This cable offers exceptional performance with low attenuation and high bandwidth, supporting 10 Gbps and beyond. The LSZH jacket reduces toxic smoke and halogen emissions in case of fire, enhancing safety in enclosed spaces. The durable construction and compliance with international standards guarantee long-term reliability.

Suitable for

• Data center cabling
• Enterprise network backbone
• Telecommunications infrastructure
• High-speed data transmission (10 Gbps, 40 Gbps)
• Fiber-to-the-desk applications

Key specifications

• Product Type: Fiber Optic Patch Cable
• Fiber Type: Multimode OM4
• Fiber Count: 4
• Connector Type A: LC-Duplex
• Connector Type B: LC-Duplex
• Cable Length: 100 m
• Core/Cladding Diameter: 50/125 µm
• Jacket Material: LSZH (Low Smoke Zero Halogen)
• Jacket Color: Aqua
• Outer Cable Diameter: Approx. 4.5 mm
• Attenuation (850nm): ≤ 2.3 dB/km
• Attenuation (1300nm): ≤ 0.6 dB/km
• Bandwidth (850nm OFL): 4700 MHz*km
• Bandwidth (1300nm OFL): 500 MHz*km
• Insertion Loss (Max. per connector pair): ≤ 0.25 dB
• Return Loss (Min. per connector): ≥ 30 dB
• Operating Temperature: -10 to +60 °C
• Storage Temperature: -20 to +70 °C
• Minimum Bend Radius (Installation): 45 mm
• Standards Compliance: IEC 60793-2-10 type A1a.3, ISO/IEC 11801, EN 50173-1, TIA/EIA-568-C.3

Recommendations

For optimal performance, ensure proper handling and installation to avoid bending beyond the minimum bend radius. This cable is compatible with standard LC-Duplex interfaces and is suitable for use with OM4 transceivers.
