Unmanaged Switch Lanview LVN-1UMOUNT-24PORT-1G 24-Port Gigabit Ethernet Switch, 1U-Einbau

Lanview LVN-1UMOUNT-24PORT-1G is an unmanaged 24-port Gigabit Ethernet switch in a 1U rack-mount form factor, designed to extend wired network capacity with minimal setup. The device provides 24 full Gigabit ports for high-speed connectivity and operates as a plug-and-play solution without the need for configuration, making it suitable for straightforward deployments in small offices, network cabinets and edge locations.

Advantages

This unmanaged Gigabit switch delivers consistent wired performance across 24 ports while eliminating configuration complexity. The 1U rack-mount chassis conserves rack space and integrates into standard network cabinets. With full-duplex Gigabit throughput on each port, the unit supports common office networking demands such as file transfers, VoIP and device connectivity without the overhead of managed features.

Suitable for

• Small and medium office LAN expansion
• Network closets and server racks requiring compact 1U equipment
• Edge deployments where unmanaged, reliable switching is preferred
• Connecting printers, workstations, IP phones and access points

Key specifications

• 24 Gigabit Ethernet ports (10/100/1000 Mbps) with auto-negotiation
• 1U rack-mount form factor for standard 19-inch racks
• Unmanaged operation: plug-and-play connectivity, no configuration required
• Full-duplex switching capability for simultaneous transmit and receive
• Store-and-forward forwarding method with MAC address learning
• Standard Ethernet interfaces compatible with CAT5e/CAT6 cabling
• Cooling by integrated fan(s) suitable for rack installation

How to use

Install the switch into a standard 19-inch rack using the included mounting brackets and secure it in a 1U space. Connect network devices using appropriate Ethernet cables to any of the 24 Gigabit ports; the ports will auto-negotiate speed and duplex. Power the device from a standard AC outlet and verify link/activity LEDs to confirm connections. No management interface or software configuration is required for basic operation; the switch will forward traffic between connected devices automatically based on learned MAC addresses.

Recommendations

Place the switch in a ventilated rack or cabinet and maintain adequate airflow around the unit. Use quality Cat5e or Cat6 cabling for reliable Gigabit performance and separate power circuits for critical network equipment when possible. For environments requiring VLANs, traffic monitoring or advanced QoS, consider a managed switch alternative; for simple expansion and straightforward wired connectivity, this unmanaged 24-port Gigabit switch provides an efficient solution.
