HellermannTyton HelaCon Easy Σύνδεσμος καλωδίων push-in 3-πολικός πράσινος 0,5-2,5mm² 450V 24A 435-12061

Electricians and panel builders use the HellermannTyton HelaCon Easy push-in wire connector for fast, tool-free joining of solid and stranded conductors in junction boxes, luminaires and control cabinets. The green 3-pole connector accepts conductors from 0.5 to 2.5 mm² and is rated for 450 V and 24 A, making it suitable for lighting and power distribution circuits.

Key specifications

• Connection method: push-in
• Number of poles: 3
• Conductor cross-section: 0.5 - 2.5 mm² (solid and stranded)
• Rated voltage: 450 V
• Rated current: 24 A
• Stripping length: 11 mm
• Insulation material: polyamide (PA66)
• Operating temperature: -30 °C to +85 °C
• Test point: yes

Why choose it

The HelaCon Easy speeds up installation with a simple push-in mechanism that requires no tools. Its compact design saves space in enclosures, and the transparent housing allows visual confirmation of the conductor position. The connector is suitable for both solid and stranded conductors, offering flexibility in wiring applications.

Ideal use cases

• Connecting lighting fixtures in residential and commercial buildings
• Wiring junction boxes and distribution boards
• Joining conductors in control cabinets and machinery

Good to know

The connector features a test point for convenient voltage testing during commissioning and maintenance. It is made from flame-retardant PA66 material with a UL94 V-2 rating.
