Grafenthal Καλώδιο patch Cat6 S/FTP CU 0,5m γκρι

The Grafenthal Patch Cable Cat6 S/FTP CU is a high-performance Ethernet cable designed for reliable, high-speed network connections. With a length of 0.5 meters, it is ideal for short-distance patching in data centers, server rooms, and home networks. The cable features S/FTP shielding (screened and foiled twisted pairs) to minimize electromagnetic interference, ensuring stable data transmission. Constructed with high-quality copper conductors and a LSZH (Low Smoke Zero Halogen) jacket, it offers both durability and safety. The snagless RJ45 connectors with gold-plated contacts provide secure connections and corrosion resistance.

Advantages

This patch cable delivers excellent performance for 10 Gigabit Ethernet (10GBASE-T) networks, supporting bandwidth up to 250 MHz. The S/FTP shielding protects against crosstalk and external noise, making it suitable for environments with high electrical interference. The LSZH jacket reduces toxic smoke in case of fire, enhancing safety. PoE support (PoE, PoE+, 4PPoE) allows power and data transmission over a single cable, simplifying installations.

Suitable for

• Data centers and server rooms
• Enterprise and home networks
• High-speed internet connections (up to 10 Gbps)
• PoE devices such as IP cameras, access points, and VoIP phones
• Industrial environments requiring robust shielding

Key specifications

• Cable Type: Patch Cable
• Cable Category: Cat6
• Shielding Type: S/FTP
• Conductor Material: Copper (CU)
• Conductor Gauge: AWG 26/7 (Stranded)
• Jacket Material: LSZH
• Cable Length: 0.5 m
• Cable Color: Grey
• Connector Type: RJ45 Male to RJ45 Male
• Connector Plating: Gold-plated (50µm)
• Wiring Standard: TIA/EIA 568B
• Max Bandwidth: 250 MHz
• Max Data Rate: 10 Gbps
• PoE Support: Yes (PoE, PoE+, 4PPoE)
• Halogen Free: Yes
• Flame Retardant: Yes
• Boot Type: Snagless
• Outer Diameter: Approx. 6.2 mm
• Compliance: RoHS, CE

Recommendations

For optimal performance, use this cable with Cat6 or higher compatible network equipment. Ensure proper cable management to avoid kinking or sharp bends. This cable is ideal for short patch connections where space is limited.
