EFB Elektronik 8-Pin Pin Header Connector, γκρι, 2,54 mm Pitch, E-WP 5461

The EFB Elektronik 8-pin pin header connector (model 20008.3) is a high-quality, single-row male connector designed for reliable board-to-board and wire-to-board interconnections. With a 2.54 mm pitch and grey PBT insulation, this through-hole component is ideal for a wide range of electronic applications. The connector features brass contacts with tin plating, ensuring excellent conductivity and durability. It is RoHS compliant and rated UL94V-0 for flammability, making it suitable for demanding environments.

Advantages

This pin header offers a robust and cost-effective solution for connecting PCBs and wires. Its straight orientation and through-hole mounting simplify assembly, while the 3 A current rating and 250 V voltage rating provide ample performance for typical electronic circuits. The wide operating temperature range (-40°C to +105°C) ensures reliability in various conditions.

Suitable for

• Board-to-board connections in industrial electronics
• Wire-to-board interconnects in consumer devices
• Prototyping and development boards
• Automation and control systems

Key specifications

• Connector Type: Pin Header (Male)
• Number of Positions: 8
• Pitch: 2.54 mm
• Colour: Grey
• Mounting Type: Through-Hole
• Orientation: Straight
• Number of Rows: Single
• Current Rating: 3 A
• Voltage Rating: 250 V
• Insulation Material: PBT
• Contact Material: Brass
• Contact Plating: Tin
• Operating Temperature: -40°C to +105°C
• Flammability Rating: UL94V-0
• RoHS Compliant: Yes

Recommendations

For optimal performance, ensure proper soldering and avoid exceeding the rated current and voltage. This connector is compatible with standard 2.54 mm pitch female headers and IDC sockets.
