BLACK BOX Modular VGA/DVI & USB HID Transmitter

The BLACK BOX Modular VGA/DVI & USB HID Transmitter (ACX1MT-VDHID-2S) is a high-performance KVM over IP transmitter designed for extending video and USB signals over a standard Gigabit Ethernet network. It supports dual DVI-I inputs (compatible with DVI-D and VGA via adapter) and provides local DVI-I outputs for monitoring. With near-zero latency and visually lossless video compression, this transmitter ensures real-time, high-quality transmission of resolutions up to 1920 x 1200 @ 60Hz per head. It also supports USB HID devices (keyboard and mouse) and stereo audio, making it ideal for remote workstation access, control room applications, and digital signage.

Advantages

This transmitter offers exceptional flexibility and reliability for KVM extension over IP. Its modular design allows integration with various video interfaces, while advanced security features (AES 128-bit encryption and RSA 2048-bit authentication) protect sensitive data. The near-zero latency (<5ms) ensures seamless user experience even for demanding tasks. Additionally, the device is OS-independent and can be managed via web browser or CLI, simplifying deployment and maintenance.

Suitable for

• Remote workstation access in data centers and server rooms
• Control room environments requiring real-time video and USB extension
• Digital signage and broadcast applications
• Industrial automation and monitoring systems

Key specifications

• Product Type: KVM over IP Transmitter
• Video Input: 2x DVI-I (supports DVI-D and VGA via adapter)
• Video Output (Local): 2x DVI-I
• Max Resolution: 1920 x 1200 @ 60Hz per head
• USB Support: USB HID (Keyboard, Mouse)
• Audio: Stereo In/Out (3.5mm jacks)
• Network: 1x Gigabit Ethernet (RJ45)
• Video Compression: Visually Lossless (user selectable)
• Latency: <5ms
• Security: AES 128-bit encryption, RSA 2048-bit authentication
• Power: External 12V DC adapter included
• Mounting: Desktop or rack-mountable (optional kit)
• Management: Web browser, CLI

Recommendations

For optimal performance, use CAT6 or higher cabling and ensure your network supports Gigabit Ethernet. The transmitter is compatible with BLACK BOX receivers (sold separately) for complete KVM over IP solutions. Consider the optional rack-mount kit for organized installation in server racks.
