TP-Link Omada EAP225-Outdoor 1200 Mbit/s Λευκό Power over Ethernet (PoE)

The EAP225 is an affordable business-class 802.11ac Wave 2 MU-MIMO access point that provides dual-band Wi‑Fi performance for small and medium business environments. It delivers combined wireless speeds up to 1350 Mbps and supports centralized cloud management with Omada controllers for easy deployment and remote monitoring.

Advantages

Equipped with MU‑MIMO Wave 2 technology, the EAP225 can serve multiple devices simultaneously, improving overall network throughput. Cloud-based management via the Omada Hardware Controller (OC200) or Omada Software Controller allows real‑time monitoring and remote configuration. Built‑in captive portal features including Facebook Wi‑Fi and SMS authentication enable secure and convenient guest access. Flexible power options—802.3af PoE and passive PoE—simplify installation and placement. The free Omada mobile app provides quick setup and on‑the‑go network management.

Key specifications

• Wireless standard: 802.11ac Wave 2 (MU‑MIMO)
• Maximum dual‑band speed: up to 1350 Mbps
• Management: Omada Hardware Controller (OC200) or Omada Software Controller; cloud management supported
• Guest authentication: captive portal with Facebook Wi‑Fi and SMS authentication
• Power options: 802.3af PoE and Passive PoE (includes PoE adapter)
• Mobile app: Omada app for configuration, monitoring and client management

How to use

Install the EAP225 in a central location and power it using a compatible 802.3af PoE switch or the supplied passive PoE adapter. Use the Omada Hardware Controller OC200 or install the Omada Software Controller to register and centrally manage the access point. Configure SSIDs, security settings and guest portal options through the controller interface or via the Omada mobile app. Monitor client connections and network status from the controller dashboard or the app.

Recommendations

For best performance place the EAP225 away from large metal objects and sources of interference; use the Omada controller to apply firmware updates and optimize channel settings. Consider deploying multiple EAP225 units managed by an OC200 or Omada Software Controller to achieve full coverage in larger premises.
