Televes Easy-Line δορυφορικό πιάτο 60cm ανθρακί (793202)

Weak satellite signals and flimsy dishes can ruin your TV experience, but the Televes Easy-Line 60cm satellite dish eliminates those frustrations with robust construction and precise signal capture. Built from powder-coated aluminum, this dish withstands harsh weather while maintaining a sleek anthracite finish. The back mount, feed arm, and LNB holder are all painted in the same reflector color for a cohesive look. With a gain of 35.5 dB at 12.75 GHz and an efficiency over 70%, it ensures reliable reception across the 10.7–12.75 GHz frequency range. The offset design (25° offset angle, F/D ratio 0.6) minimizes signal blockage, and the 40mm LNB clamp and 30–50mm mast clamp offer flexible installation. Rated for wind loads up to 110 kg at 150 km/h, this dish is built to last.

Who is it for

Ideal for homeowners and installers seeking a durable, high-performance satellite dish for receiving free-to-air or subscription satellite TV. It suits both urban and rural settings, especially in areas with moderate to strong winds, thanks to its sturdy aluminum build and corrosion resistance.

Main features

• 60cm powder-coated aluminum reflector for durability and corrosion resistance
• Anthracite color with matching back mount, feed arm, and LNB holder
• High gain of 35.5 dB at 12.75 GHz for strong signal reception
• Wide frequency range 10.7–12.75 GHz, compatible with most Ku-band satellites
• Offset design with 25° offset angle and F/D ratio 0.6 for reduced signal blockage
• 40mm LNB clamp and 30–50mm mast clamp for versatile mounting
• Elevation adjustment 0–90° for precise alignment
• Withstands wind loads up to 110 kg at 150 km/h
• Linear polarization and efficiency >70% for optimal performance

Specifications

• Reflector diameter: 60 cm
• Reflector material: Powder-coated aluminum
• Color: Anthracite
• Gain at 12.75 GHz: 35.5 dB
• Frequency range: 10.7–12.75 GHz
• F/D ratio: 0.6
• Offset angle: 25°
• LNB clamp diameter: 40 mm
• Mast clamp diameter: 30–50 mm
• Elevation adjustment range: 0–90°
• Wind load at 130 km/h: 80 kg
• Wind load at 150 km/h: 110 kg
• Corrosion resistance: High (powder-coated)
• Mounting type: Azimuth/Elevation mount
• Series: Easy-Line
• Polarization: Linear
• Efficiency: >70%

Tips

For best results, use a signal meter during installation to fine-tune the azimuth and elevation. Pair with a high-quality LNB (not included) to maximize signal strength. Ensure the mast is securely anchored, especially in high-wind areas. Periodically check that all bolts are tight and the dish is free of debris.
