Telegärtner αρθρωτή μονάδα Keystone RJ45 Cat.6A θωρακισμένη πράσινη 1 θύρα

The Telegärtner Modular Input Keystone Module is a high-performance RJ45 jack designed for structured cabling systems. It supports Category 6A (Class EA) transmission up to 500 MHz, making it ideal for 10 Gigabit Ethernet (10GBASE-T) applications. The module is fully shielded (STP/FTP) to protect against electromagnetic interference and is compatible with PoE, PoE+, and 4PPoE (IEEE 802.3af/at/bt).

Advantages

Robust die-cast zinc housing ensures durability and reliable shielding. The IDC termination (LSA-Plus compatible) allows for quick and secure installation, either tool-less or with an LSA tool. Universal wiring scheme T568A/B provides flexibility for various network configurations. With over 750 insertion cycles, this module offers long-lasting performance.

Suitable for

• Data centers and server rooms requiring high-speed 10GbE connections
• Enterprise networks needing reliable, shielded cabling
• PoE-powered devices such as cameras, access points, and IoT equipment
• Structured cabling installations in commercial and industrial environments

Key specifications

• Connector Type: RJ45 Jack
• Category: Cat.6A (Class EA)
• Shielding: Shielded (STP/FTP)
• Wiring Scheme: T568A/B (Universal)
• Color: Green
• Number of Ports: 1
• Mounting Type: Keystone Module
• Housing Material: Die-cast zinc
• Contact Material: Phosphor bronze with gold plating
• Termination Type: IDC (LSA-Plus compatible)
• Transmission Performance: Up to 500 MHz
• PoE Support: PoE, PoE+, 4PPoE (IEEE 802.3af/at/bt)
• Application: 10 Gigabit Ethernet (10GBASE-T)
• Standard Compliance: ISO/IEC 11801, EN 50173, TIA/EIA-568-C.2
• Operating Temperature: -40°C to +70°C
• Insertion Cycles: >750
• Cable Diameter Range: AWG 24/1 - 22/1 (solid), AWG 26/7 - 22/7 (stranded)

Recommendations

For optimal performance, use with Cat.6A shielded patch cables and ensure proper grounding. This module is an excellent choice for high-density patch panels and keystone jacks in 19-inch racks.
