Rittal VX Πλαίσιο τοποθέτησης rack 24U RAL 7035

The Rittal VX Rack Mounting Frame is a robust 19-inch rack frame designed for use with the VX25 enclosure system. It provides a reliable mounting solution for IT, network, server, and industrial control applications. The frame is made from sheet steel with a light grey (RAL 7035) dipcoat-primed and powder-coated finish, ensuring durability and a professional appearance.

Advantages

High static load capacity of up to 1500 N (approx. 150 kg) allows for heavy equipment installation. The frame is easy to install with front and rear mounting angles, and it integrates seamlessly into the inner mounting level of VX25 enclosures.

Suitable for

• 19-inch rack mounting in Rittal VX25 enclosures
• IT and network equipment installation
• Server and industrial control systems

Key specifications

• Product Type: Rack Mounting Frame
• Compatibility: Rittal VX25 Enclosure System
• Rack Standard: 19-inch
• Rack Units: 24 U
• Material: Sheet Steel
• Color: Light Grey (RAL 7035)
• Surface Finish: Dipcoat-primed, Powder-coated
• Mounting Position: Inner mounting level of VX25 enclosure
• Static Load Capacity: 1500 N (approx. 150 kg)
• Mounting Type: Front and rear mounting angles
• Scope of Supply: 2 x 19" mounting angles, assembly parts
• Mounting Width: 482.6 mm (19")
• Mounting Height: 1066.8 mm (24 U)
• Environmental Category: Indoor Use

Recommendations

For optimal performance, ensure the frame is installed in a suitable VX25 enclosure and that the total load does not exceed the specified capacity. Use appropriate mounting hardware and follow the manufacturer's instructions.
