Pulsar AWT682 12V DC 5A 60W Τροφοδοτικό διακοπτόμενης λειτουργίας

The Pulsar AWT682 is a high-efficiency switching power supply (SMPS) designed for professional CCTV, access control, and alarm systems. It delivers a stable 12V DC output with up to 5A current (60W) and features a wide input voltage range of 170-260V AC, making it suitable for demanding security installations.

Advantages

Compact open-frame PCB module design for easy integration into control cabinets. Built-in protections against short circuits, overload, overvoltage, and undervoltage ensure reliable operation. LED status indicator for quick diagnostics. High efficiency >80% reduces energy waste and heat generation.

Suitable for

• CCTV cameras and DVRs
• Access control systems (electric locks, readers)
• Alarm panels and security sensors
• Low-voltage automation and control applications

Key specifications

• Input: 230V AC (170-260V AC), 50Hz
• Output: 12V DC, adjustable 11-13.8V DC
• Output current: 5A, power: 60W
• Protection: SCP, OLP, OVP, UVP
• Ripple & noise: <100mVp-p
• Operating temperature: -10°C to +40°C
• Connection: Screw terminals
• Enclosure: Open frame PCB module

Recommendations

For optimal performance, use with compatible 12V DC devices. Ensure adequate ventilation and mounting in a dry, dust-free environment. Always observe local electrical codes during installation.
