Phoenix 3032428 UAB Βάση στήριξης για ράγα DIN, Πολυαμίδιο, Γκρι

In industrial control cabinets, heavy components such as power supplies or interface modules can strain standard DIN rail mounts. The Phoenix 3032428 Auflagebock UAB support bracket solves this by providing a robust, snap-on reinforcement for NS 35/7.5 and NS 35/15 rails. Made from gray polyamide (PA) with UL 94 V0 flammability rating, it ensures stable support and safe operation even under mechanical load.

Key specifications

• Product type: Support bracket
• Mounting: DIN rail NS 35/7.5 and NS 35/15
• Material: Polyamide (PA)
• Color: Gray
• Flammability rating: UL 94 V0
• Operating temperature: -60 °C to 105 °C
• Insulating material group: I (IEC 60664)
• Installation: Snap-on
• Humidity range: 30 % ... 70 % (at 25 °C)
• Environmental compliance: RoHS, REACH
• Country of origin: Germany

Why choose it

This bracket is engineered for reliability in demanding environments. The UL 94 V0 rating means it resists ignition, reducing fire risk in densely packed cabinets. Its wide temperature tolerance from -60 °C to 105 °C makes it suitable for both cold storage and high-heat industrial settings. The snap-on design allows quick installation without tools, saving time during assembly or retrofits.

Ideal use cases

• Supporting heavy power supplies on DIN rails in control panels
• Reinforcing mounting points for interface modules and relays
• Use in machinery with vibration or shock loads
• Applications requiring halogen-free, self-extinguishing materials

Good to know

The bracket is part of Phoenix Contact's comprehensive DIN rail accessory range, ensuring compatibility with standard 35 mm rails. It complies with RoHS and REACH, meeting strict environmental standards. For optimal performance, install in environments with 30–70% relative humidity at 25 °C.
