Μονάδα πομποδέκτη οπτικής ίνας BlueOptics SPP-10S-LR-CDFC-BO 10000 Mbit/s SFP+

The BlueOptics SPP-10S-LR-CDFC-BO is a 10G SFP+ fiber optic transceiver module designed for high-speed single-mode links. It supports data rates up to 10000 Mbit/s and uses an LC duplex connector for simultaneous transmit and receive over separate fibers. The module comes in a metal housing with a compact form factor and a lightweight design (approx. 20 g). It implements industry-standard electrical and mechanical SFP+ interfaces and provides long-service MTBF performance for network installations.

Advantages

The module provides 10GBASE-LR performance for distances up to typical single-mode link ranges, combined with a sturdy metal enclosure for mechanical stability and thermal dissipation. Digital Diagnostics Monitoring (DDM/DOM) is supported to enable remote monitoring of supply voltage, laser bias current, transmit output power, received input power and internal temperature, facilitating diagnostics and maintenance. Compliance with MSA form-factor and common industrial standards ensures broad interoperability with network switches, routers and storage equipment that accept SFP+ modules.

Suitable for

• 10 Gigabit Ethernet uplinks and inter-switch links over single-mode fiber
• High-speed connections in data centers and server rooms
• Fibre Channel over Ethernet and SDH/SONET transport applications
• Replacement or compatibility deployments in systems supporting standard SFP+ LR transceivers

Key specifications

• Interface type: SFP+
• Maximum data transfer rate: 10000 Mbit/s
• Optical fiber type: single-mode fiber (LC duplex connector)
• Wavelength: 1310 nm (transmit and receive)
• Form factor: SFP+ metal housing
• Typical reach: long-reach single-mode links (standard 10GBASE-LR class)
• Digital Diagnostics Monitoring: supported (DDM/DOM, SFF-8472 compliant)
• Weight: approx. 0.02 kg

How to use

Install the transceiver into an empty SFP+ port on a compatible switch, router or host adapter by aligning the module and pressing it into the cage until it latches. Connect LC duplex single-mode patch cables to the transmit and receive ports according to the labeling. Verify link status and, if available, check DDM/DOM values through the host system to confirm optical power levels and temperature. When removing the module, release the latch and gently pull the module straight out to avoid damaging the connector.

Recommendations

Use high-quality single-mode LC duplex fiber patch cords and ensure polarity is correct for transmit/receive pairing. Confirm that the target hardware supports SFP+ LR transceivers and DDM/DOM if remote diagnostics are required. For stable long-term operation, avoid exposing the module to extreme temperatures and mechanical stress; follow the host equipment manufacturer’s guidelines for hot-swap handling.
