Lenovo DB610S ENT BUNDLE TRK FV EF IN (7S0C000CWW)

The Lenovo DB610S ENT BUNDLE TRK FV EF IN (7S0C000CWW) is a 32Gbps Fibre Channel SAN switch that delivers enterprise-class performance in a compact 1U form factor. Unlike typical entry-level switches, it offers 24 ports expandable to 48, enabling high-density connectivity for growing storage networks. With port-to-port latency of 700 ns and aggregate throughput up to 1.536 Tbps, it accelerates data-intensive applications.

Highlights

• 32Gbps Fibre Channel speed with 24 SFP28 ports, expandable to 48
• Dual hot-swappable power supplies and fan trays for high availability
• Advanced fabric services: Brocade Fabric Vision, ISL Trunking, Adaptive Networking, Extended Fabrics
• Low latency of 700 ns for rapid data access
• Comprehensive management via CLI, Web Tools, and SNMP

In daily use

The DB610S simplifies SAN management with intuitive tools and robust diagnostics. Its redundant components minimize downtime, while the 1U rackmount design conserves data center space. The switch supports 32Gb, 16Gb, and 8Gb FC transceivers, ensuring compatibility with existing infrastructure. Shared buffer credits of 2048 across 48 ports optimize performance in mixed workloads.

Full specifications

• Product Type: Fibre Channel SAN Switch
• Form Factor: 1U Rackmount
• Port Configuration: 24-port (base), expandable to 48-port
• Port Type: SFP28
• Aggregate Throughput: Up to 1.536 Tbps (full duplex)
• Latency: 700 ns (port-to-port)
• Power Supply: Dual, hot-swappable, redundant
• Cooling: Hot-swappable fan trays
• Management Interfaces: CLI, Web Tools, SNMP
• Supported Protocols: Fibre Channel (FC)
• Included Software Features: Brocade Fabric Vision, ISL Trunking, Adaptive Networking, Extended Fabrics
• Max Frame Size: 2112 bytes
• Buffer Credits: 2048 (shared across 48 ports)
• Power Consumption: 100W (with 24x 32Gbps SFP28 transceivers)
• Operating Temperature: 0°C to 40°C (32°F to 104°F)
• Humidity Range: 10% to 85% (non-condensing)

Final note

The DB610S is engineered for organizations seeking high-performance SAN connectivity with scalability and reliability, backed by Lenovo's enterprise support ecosystem.
