Κάρτα δικτύου DELL Broadcom 57414 εσωτερική οπτικών ινών 25000 Mbit/s

The DELL Broadcom 57414 is an internal fiber network card designed for servers and workstation systems requiring high-speed wired connectivity. This dual-port PCIe adapter supports 10/25Gb SFP28 connections and has been tested and validated on Dell systems; Dell Technical Support provides assistance when used with a Dell system.

Advantages

The Broadcom 57414 offers standards-based reliability and compatibility with Dell platforms, delivers up to 25 Gbit/s per port over SFP28 fiber, and uses a PCI Express host interface for direct integration into server motherboards. Its tested status on Dell systems ensures driver and firmware support within Dell environments.

Suitable for

• High-performance server networking
• Data center uplinks and aggregation
• Virtualization hosts and storage networks
• Environments requiring 10GbE to 25GbE fiber connectivity

Key specifications

• Brand: Dell
• Model: Broadcom 57414 (MPN 540-BDHY)
• Interface: Fiber (SFP28)
• Host interface: PCI Express
• Maximum data transfer rate: 25000 Mbit/s (25 Gbit/s)
• Connectivity technology: Wired
• Product colour: Green
• EAN: 5397184923207

How to use

Install the card into an available PCI Express slot on a compatible Dell server or workstation following the system manufacturer's installation guidelines. Insert SFP28 fiber modules and connect appropriate fiber cabling to network switches or transceivers configured for 10/25Gb operation. Install or update drivers and firmware as provided by Dell to ensure full functionality and validation on Dell systems.

Recommendations

Use compatible SFP28 transceivers and fiber cabling rated for 25Gb operation, keep drivers and firmware up to date via Dell support, and verify compatibility with your specific Dell system model to ensure supported operation and access to Dell Technical Support.
