GRAFENTHAL Καλώδιο Patch Cat6 S/FTP CU 0,5m Γκρι

The GRAFENTHAL Patch Cable Cat6 S/FTP CU is a high-performance Ethernet patch cable designed for reliable, high-speed network connections. With a length of 0.5 meters and a sleek grey LSZH jacket, this cable is ideal for short-distance patching in data centers, server rooms, and home networks. It supports up to 10 Gigabit Ethernet (10GBASE-T) and features S/FTP shielding (pairs in metal foil with overall braid) to minimize electromagnetic interference, ensuring stable data transmission.

Advantages

This cable offers superior signal integrity and protection against crosstalk and external noise thanks to its S/FTP shielding and 100% copper stranded conductors. The LSZH jacket makes it safe for use in enclosed spaces, as it emits low smoke and no halogen in case of fire. Gold-plated RJ45 connectors (50µm) ensure corrosion resistance and optimal conductivity.

Suitable for

• Connecting computers, switches, routers, and patch panels in local area networks (LAN)
• Data centers and server rooms requiring high-density cabling
• Home and office networks demanding reliable 10Gbps performance
• Applications where fire safety and low smoke emission are critical

Key specifications

• Cable Type: Patch Cable
• Category: Cat6
• Shielding: S/FTP (PIMF)
• Conductor Material: 100% Copper (CU)
• Conductor Type: Stranded
• AWG: 26 AWG
• Jacket Material: LSZH (Low Smoke Zero Halogen)
• Cable Length: 0.5 m
• Colour: Grey
• Connector Type: RJ45 Male to RJ45 Male
• Connector Plating: Gold-plated (50µm)
• Wiring Standard: TIA/EIA 568B
• Bandwidth: Up to 250 MHz
• Data Transfer Rate: Up to 10 Gigabit Ethernet (10GBASE-T)
• Compatibility: Ethernet networks (10/100/1000/10000 Mbps)
• Halogen Free: Yes
• Flame Retardant: Yes (IEC 60332-1-2)
• Operating Temperature: -20°C to 60°C
• Outer Diameter: Approx. 6.2 mm
• Number of Pairs: 4

Recommendations

For optimal performance, use this cable with Cat6 or higher compatible devices. Ensure proper cable management to avoid sharp bends and maintain signal quality.
