GRAFENTHAL Καλώδιο Patch CAT6 S/FTP CU 0,5m Γκρι

The GRAFENTHAL Patch Cable CAT6 S/FTP CU is a high-performance network cable designed for reliable 10 Gigabit Ethernet connections. With S/FTP shielding and pure copper conductors, it ensures minimal crosstalk and interference, making it ideal for demanding data center and enterprise environments.

Advantages

This cable offers superior signal integrity and durability. The gold-plated RJ45 connectors provide excellent conductivity and corrosion resistance, while the snagless boot design protects the locking tab during installation. The LSZH jacket reduces toxic smoke in case of fire, enhancing safety in enclosed spaces.

Suitable for

• Data centers and server rooms requiring high-speed, reliable connections
• Enterprise networks where interference protection is critical
• 10GBASE-T applications over short distances
• Structured cabling systems in commercial buildings

Key specifications

• Cable Type: Patch Cable
• Category: CAT6
• Shielding: S/FTP (Screened Foiled Twisted Pair)
• Conductor Material: Copper (CU)
• Length: 0.5 m
• Connector: RJ45 (8P8C) with gold-plating (50µm)
• Jacket Material: LSZH
• Colour: Grey
• Bandwidth: Up to 250 MHz
• Data Transfer Rate: Up to 10 Gbit/s
• Conductor Gauge: AWG 27/7 (stranded)
• Wiring Standard: TIA/EIA 568B
• Boot Type: Snagless / Molded
• Number of Pairs: 4
• Outer Diameter: Approx. 6.0 mm
• Compliance: RoHS, CE

Recommendations

For optimal performance, use this cable with CAT6-compatible switches and network interfaces. Ensure proper cable management to avoid bending beyond the minimum bend radius.
