EFB Elektronik Cat.7 S/FTP LSZH καλώδιο patch, RJ45, 0,25 m, μαύρο K0700SW.0,25

This EFB Elektronik patch cable is a raw, unassembled Cat.7 cable, ideal for custom installations where you terminate your own connectors. Unlike pre-made patch leads, it gives you the flexibility to cut to exact length and choose your own RJ45 plugs. The S/FTP shielding with PIMF (pairs in metal foil) provides excellent protection against alien crosstalk, making it suitable for 10 Gigabit Ethernet in demanding environments.

Highlights

• Cat.7 performance up to 600 MHz, supports 10GBASE-T
• S/FTP: overall braid shield plus foil per pair (PIMF)
• LSZH jacket: low smoke, zero halogen for safety
• Bare copper conductors, AWG26, 4 pairs
• Length: 0.25 m, black jacket

In daily use

Use this cable for structured cabling, patch panels, or direct equipment connections where you need a short, high-performance link. The LSZH jacket is essential in public buildings, data centers, and anywhere fire safety is a concern. Because it is a raw cable, you will need to attach RJ45 connectors yourself, following TIA/EIA-568B wiring.

Full specifications

• Cable category: Cat.7
• Shielding: S/FTP (Screened/Foiled Twisted Pair)
• Jacket material: LSZH (Low Smoke Zero Halogen)
• Length: 0.25 m
• Colour: Black
• Connector type: RJ45 male (not included; cable only)
• Data transfer rate: up to 10 Gbps
• Bandwidth: up to 600 MHz
• Wiring standard: TIA/EIA-568B
• Conductor material: bare copper
• Conductor gauge: AWG26
• Number of pairs: 4
• Pair shielding: aluminum foil (PIMF)
• Overall shielding: tinned copper braid
• Contact plating: gold-plated (50µ")
• Application: LAN, data center, server rack
• Fire safety: IEC 60332-1, IEC 61034, IEC 60754-2

Final note

This cable is supplied without connectors, giving you full control over termination. Ensure you use Cat.7 compatible RJ45 plugs to maintain performance.
