Διακόπτης βίντεο HDMI ROLINE 14.01.3575

The ROLINE 14.01.3575 4K HDMI switch is a compact 3-way video switch that lets you connect up to three HDMI sources (for example DVD player, video camera or game console) to a single monitor or TV. It supports HDMI High Speed and delivers video at resolutions up to 3840 x 2160 at 60 Hz, while remaining compatible with common SD and HD modes.

Advantages

The switch supports HDMI High Speed and both uncompressed (LPCM) and compressed audio formats including DTS Digital and Dolby Digital (including DTS-HD and Dolby TrueHD). Input selection can be done using the button on the unit or the included remote control. The device is powered by an external 5 V DC, 1 A adapter and comes in a compact black enclosure that is easy to place in any setup.

Suitable for

• Connecting multiple HDMI sources to a single display
• Home entertainment systems with DVD players, consoles and cameras
• Small offices or meeting rooms requiring simple source switching

Key specifications

• Brand: ROLINE, Model: 14.01.3575
• Video port type: HDMI
• Supported graphics resolutions: up to 3840 x 2160 @ 60 Hz (4K60)
• Supported video modes: 480p, 576p, 720p, 1080i, 1080p, 2160p
• Audio support: LPCM and compressed formats (DTS Digital, Dolby Digital, DTS-HD, Dolby TrueHD)
• Inputs: 3 HDMI sources (3-way switch)
• Power supply: 5 V DC, 1 A (required)
• Colour: Black
• Dimensions (W×D×H): 80 × 58 × 18 mm

How to use

Connect up to three HDMI source devices to the HDMI input ports on the switch and connect the HDMI output to your monitor or TV. Plug in the 5 V DC power adapter. Use the button on the device or the supplied remote control to cycle between connected inputs. Ensure source devices and the display are powered on and set to compatible resolutions for best results.

Recommendations

For reliable 4K@60Hz performance use high-quality HDMI High Speed cables and confirm that the connected source and display both support the chosen resolution and audio formats.
