Busch-Jaeger Συνδυαστικός διακόπτης ροκέρ 2601/6/20 EAPBJ-522 (2TKA00005537)

This Busch-Jaeger combination rocker switch insert stands out with its dual-function switching capability, handling both off and two-way circuits in a single compact unit. Built for flush-mounted installation, it integrates seamlessly into standard wall boxes and pairs with a wide range of Busch-Jaeger rocker covers and frames for a cohesive look.

Highlights

• Combination switch function: off and two-way switching in one device
• Rated for 250 V AC and 10 A, suitable for general lighting control
• Screw terminals ensure secure, reliable wiring connections
• Thermoplastic construction, halogen-free and grey insert
• Compatible with separate indicator lamp for illuminated switching

In daily use

The switch insert provides a straightforward solution for controlling lighting from one or two locations. Its rocker mechanism offers tactile feedback, and the option to add an indicator lamp enhances visibility in dark areas. The grey insert blends discreetly behind chosen rocker covers, maintaining a clean aesthetic.

Full specifications

• Switch type: Rocker switch insert
• Function: Combination switch (off/two-way)
• Rated voltage: 250 V AC
• Rated current: 10 A
• Connection type: Screw terminals
• Mounting type: Flush-mounted
• Number of poles: 1-pole
• Number of terminals: 3 (L, L1, L2) + N-terminal
• Illumination capability: Yes, with separate indicator lamp
• Material: Thermoplastic
• Halogen-free: Yes
• Protection class (IP): IP20
• Switching principle: Rocker
• Colour (insert): Grey
• Certification: VDE
• Application: Lighting control, general switching
• Operating temperature: -5 to +40 °C

Final note

This insert is the core switching mechanism; rocker covers and frames are ordered separately to complete the installation.
