Busch-Jaeger Επιτοίχια πρίζα οπτικών ινών LC Duplex, Χωνευτή, 2CKA000230A0486

Fiber optic connections in residential and commercial buildings often suffer from exposed fibers, unstable connectors, and untidy installations. The Busch-Jaeger LC Duplex Fiber Optic Wall Outlet provides a clean, flush-mounted termination point for fiber optic cables, protecting the connection and integrating seamlessly with standard switch ranges.

Who is it for

This outlet is intended for electricians, network installers, and homeowners implementing FTTH (Fiber to the Home) or LAN fiber optic cabling. It suits anyone needing a reliable, modular LC Duplex connection point that fits into standard flush-mounted device boxes and matches existing Busch-Jaeger switch designs.

Main features

• LC Duplex connector for high-density fiber optic connections
• Flush-mounted (Unterputz) installation in standard Ø 60mm device boxes
• Compatible with multimode (OM1, OM2, OM3, OM4) and singlemode (OS1, OS2) fibers
• Low insertion loss of less than 0.3 dB for reliable signal transmission
• Halogen-free thermoplastic housing for safety and durability
• Modular design requiring a separate central plate or cover from Busch-Jaeger switch ranges (future® linear, carat®, solo®, alpha®)

Specifications

• Product type: Fiber optic wall outlet
• Installation type: Flush-mounted (UP)
• Connector type: LC Duplex
• Number of ports: 1 (LC Duplex)
• Fiber compatibility: Multimode (OM1, OM2, OM3, OM4), Singlemode (OS1, OS2)
• Housing material: Thermoplastic, halogen-free
• Insertion loss: < 0.3 dB
• Return loss: > 50 dB (PC/UPC), > 60 dB (APC)
• Operating temperature: -25°C to +70°C
• Flammability rating: UL94-V0
• Standard: IEC 61754-20 (LC connector)

Tips

Order the appropriate central plate or cover separately from the Busch-Jaeger switch range that matches your interior design. The outlet itself is black/grey, so choose a cover that complements your decor. Ensure the fiber type (multimode or singlemode) matches your network equipment.
