AJA μετασχηματιστής ισχύος - για AJA D10A, D10AD, D10C2

Delivering a robust 30W of clean, regulated 12V DC power, this AJA D5/10-PC adapter is the dependable energy source your D10-series converters demand. With a wide 100–240V AC input and an efficient Energy Star Level VI design, it keeps your professional video workflow running smoothly anywhere in the world.

Overview

The AJA D5/10-PC is a compact external power adapter engineered specifically for AJA D10A, D10AD, D10C2, and other D10 series digital video converters. It converts standard AC mains power to the precise 12V DC required by these devices, ensuring stable operation in broadcast, post-production, and live event environments. The adapter features a 4-pin XLR male output connector for a secure, professional-grade connection, and an IEC C13 input that accepts common AC power cords.

What stands out

• 30W output power with 12V DC and 2.5A current for reliable converter performance.
• Universal 100–240V AC input with 50/60 Hz frequency support for global use.
• Energy Star Level VI efficiency reduces energy consumption and operating costs.
• Comprehensive protection against over-voltage, over-current, and short circuits.
• Professional 4-pin XLR male connector ensures a secure, locking connection.
• Compact desktop form factor with a generous 1.8 m DC cable for flexible placement.

Technical details

• Product Type: AC to DC Power Adapter
• Input Voltage: 100–240V AC
• Input Frequency: 50/60 Hz
• Output Voltage: 12V DC
• Output Current: 2.5A
• Output Power: 30W
• Output Connector: 4-pin XLR Male
• Input Connector: IEC C13
• DC Cable Length: 1.8 m (6 ft)
• Efficiency: Energy Star Level VI
• Operating Temperature: 0°C to 40°C (32°F to 104°F)
• Storage Temperature: -20°C to 60°C (-4°F to 140°F)
• Operating Humidity: 10% to 90% non-condensing
• Protection: Over-voltage, Over-current, Short-circuit
• Certifications: CE, FCC, UL (expected)
• Compatibility: AJA D10A, D10AD, D10C2, and other D10 series converters

Our verdict

A purpose-built power solution that matches AJA's professional standards—efficient, protected, and globally ready. The XLR connector and universal input make it a reliable choice for any D10 converter setup.
