30 θέσεων (μονής όψης) ανοιχτό, χωρίς προστασία PW

This 30-position FFC/FPC connector delivers reliable, high-density signal transmission in a compact right-angle SMT package. Its flip-lock ZIF mechanism ensures secure mating with zero insertion force, while the 0.5mm pitch and 1.0mm profile make it ideal for space-constrained electronics.

Advantages

The bottom-contact orientation and gold-plated phosphor bronze contacts provide excellent electrical performance and durability, rated for 20 mating cycles. The LCP housing withstands high temperatures up to 85°C, and the connector is RoHS compliant and halogen-free, meeting modern environmental standards.

Suitable for

• Consumer electronics: smartphones, tablets, wearables
• Industrial control systems and instrumentation
• Medical devices requiring compact interconnects
• Automotive infotainment and camera modules
• Any application needing reliable FFC/FPC connections

Key specifications

• Number of positions: 30
• Pitch: 0.5 mm
• Contact orientation: Bottom contact
• Mounting type: Surface mount (SMT)
• Orientation: Right angle
• Locking mechanism: Flip-lock (ZIF)
• Current rating: 0.5 A per contact
• Voltage rating: 50 V AC/DC
• Insulation resistance: 500 MΩ min
• Dielectric withstanding voltage: 250 V AC
• Operating temperature: -25°C to +85°C
• Durability: 20 mating cycles
• Housing material: LCP
• Contact material: Phosphor bronze
• Contact plating: Gold over nickel
• Mating height: 1.0 mm
• RoHS compliant: Yes
• Halogen free: Yes

Recommendations

For automated assembly, ensure proper solder paste stencil alignment. The connector is compatible with standard FFC/FPC cables of 0.5mm pitch. Store in a dry environment to maintain contact integrity.
