VivoLink PRO HDMI+USB και Micro VGA Επιτοίχιος Διακόπτης (PROHDMIMVGA3)

In modern meeting rooms and classrooms, the tangle of cables and the scramble to connect different devices can disrupt the flow of presentations. The VivoLink PROHDMIMVGA3 wall plate switcher solves this by providing a clean, integrated connection point for HDMI, VGA, and USB sources, all in a standard gang box form factor. It automatically switches between inputs and delivers a single HDMI output to your display, ensuring a seamless and professional AV experience.

Who is it for

This wall plate switcher is ideal for corporate meeting rooms, educational institutions, and hospitality venues that need a reliable, easy-to-use interface for multiple AV sources. It is perfect for integrators and IT professionals looking to streamline connectivity and reduce cable clutter.

Main features

• Multiple inputs: HDMI, Micro VGA, USB-B, and 3.5mm audio for versatile source connectivity.
• Automatic switching with manual RS-232 control for flexible operation.
• Supports HDMI resolutions up to 4K@30Hz (4:4:4) and 4K@60Hz (4:2:0), and VGA up to 1920x1200@60Hz.
• USB 2.0 pass-through for connecting peripherals like cameras or touch displays.
• EDID management ensures optimal display compatibility.
• Firmware upgradeable via USB Mini-B for future enhancements.
• Wall plate design fits standard gang boxes for a clean, professional installation.

Specifications

• Input connectors: 1x HDMI, 1x USB-B, 1x Micro VGA, 1x 3.5mm audio
• Output connector: 1x HDMI
• HDMI max resolution: 4K@30Hz (4:4:4), 4K@60Hz (4:2:0)
• VGA max resolution: 1920x1200@60Hz
• HDCP compliance: HDCP 1.4
• USB standard: USB 2.0 (pass-through)
• Control ports: 1x RS-232 (3-pin Phoenix), 1x USB Mini-B (firmware)
• Switching method: Automatic, RS-232 control
• Audio support: HDMI embedded, VGA audio embedding
• EDID management: Yes
• Power supply: DC 12V/1A
• Mounting type: Wall plate (standard gang box compatible)
• Product colour: Black

Tips

For best results, ensure the wall plate is installed in a standard gang box and powered with the included 12V adapter. Use high-quality HDMI cables to maintain 4K signal integrity. The USB pass-through is ideal for connecting a room camera or interactive display, and the RS-232 port allows integration with control systems for automated switching.
