Βάση TV οροφής SMS Smart Media Solutions Func 152,4 cm 60 ίντσες μαύρο μέγ. 50 kg

Func Ceiling is a ceiling TV mount designed for single displays up to 152.4 cm (60") and a maximum weight of 50 kg. The mount provides height adjustment, tilt and swivel functions, and integrated cable routing through the pole with multiple cable exits for neat installation. It supports VESA patterns from 100 x 100 mm to 400 x 400 mm and is finished in black.

Advantages

The SMS Smart Media Solutions Func Ceiling mount combines stability and clean design. It offers height adjustment from 1228 mm to 1828 mm, tilt between -3° and 25° and a 180° swivel for flexible viewing angles. Cable management is built into the pole with additional top and bottom exits, and the strengthened construction improves stability and adjustability for heavier displays.

Suitable for

• Mounting a single TV or display up to 60" (152.4 cm)
• Environments requiring adjustable height and viewing angle (meeting rooms, lobbies)
• Installations needing discreet cable routing from ceiling to display

Key specifications

• Maximum screen size: 60" (152.4 cm)
• Maximum weight capacity: 50 kg
• Height adjustment: 1228–1828 mm
• Tilt range: -3° to 25°
• Swivel: 180°
• VESA compatibility: 100 x 100 mm to 400 x 400 mm
• Product colour: Black
• Product weight: 8.4 kg

How to use

Fix the ceiling plate to a suitable structural support following local building regulations and the mount's installation instructions. Attach the bracket to the display using the appropriate VESA holes and fasteners, feed cables through the pole and route them out via the desired top or bottom exit, then secure the display to the pole. Adjust height, tilt and swivel to the preferred viewing position and tighten adjustment points according to the manual to ensure stability.

Recommendations

Ensure the ceiling structure can safely carry the combined weight of the mount and display (up to 50 kg). Use appropriate fixings for the ceiling material and follow the manufacturer's installation guide. For heavy displays or public installations, consider professional installation.
