TELTONIKA NETWORKS 4-PIN Plug with Contact - Hirschmann CA Series Circular Connector, Male, Solder, IP67, Black

The TELTONIKA NETWORKS 4-PIN plug with contact is a high-quality circular connector from the Hirschmann CA Series, designed for reliable power and signal transmission in industrial environments. This male plug features 4 silver-plated brass contacts with a solder termination, ensuring secure and durable connections. With a rated voltage of 250 V AC/DC and a rated current of 10 A, it is suitable for a wide range of applications. The connector offers an IP67 protection rating when mated, making it resistant to dust and water ingress. Its screw locking mechanism provides a robust and vibration-proof connection. The housing is made of polyamide (PA) with a black color, and the cable outlet is straight, accommodating cables up to 6 mm in diameter. Operating temperature range is -40°C to +90°C, and the flammability rating is UL 94 V-0.

Advantages

This connector ensures high reliability and long service life with up to 500 mating cycles. The silver-plated contacts offer low contact resistance (< 5 mΩ) and high insulation resistance (> 10 GΩ). The IP67 rating guarantees protection in harsh conditions, while the screw locking mechanism prevents accidental disconnection. Easy solder termination simplifies installation.

Suitable for

• Industrial automation and control systems
• Sensor and actuator connections
• Power supply and signal transmission
• Outdoor and harsh environment applications
• Telecommunications and networking equipment

Key specifications

• Connector Type: Circular Connector
• Number of Contacts: 4
• Gender: Male (Plug)
• Series: Hirschmann CA Series
• Termination Method: Solder
• Rated Voltage: 250 V AC/DC
• Rated Current: 10 A
• Protection Rating: IP67 (Mated)
• Operating Temperature Range: -40°C to +90°C
• Locking Mechanism: Screw Locking
• Housing Material: Polyamide (PA)
• Contact Material: Brass, Silver-Plated
• Cable Outlet: Straight
• Max. Cable Diameter: 6 mm
• Flammability Rating: UL 94 V-0
• Insulation Resistance: > 10 GΩ
• Contact Resistance: < 5 mΩ
• Mating Cycles: 500
• Mounting Type: Cable Mount
• Color: Black

Recommendations

For optimal performance, use with compatible Hirschmann CA series receptacles. Ensure proper soldering and cable strain relief. Suitable for use in industrial environments where reliable connections are critical.
