With a 500,000-cut life expectancy, this guillotine cutter module keeps your TSC label printer running smoothly through high-volume jobs. It cleanly separates labels, tags, or continuous media up to 108 mm wide and 0.25 mm thick, making it a reliable addition to demanding print environments.

Overview

The Taiwan Semiconductor 98-0530027-00LF is a field-installable guillotine cutter designed for TSC TTP-244 Pro, TTP-243 Pro, TTP-245 Plus, TTP-343 Plus, and TTP-345 printers. It performs full cuts automatically, controlled by the host printer, and is powered directly by the printer—no external power supply needed. The enclosed blade mechanism ensures safe operation, while its metal alloy and durable plastic construction withstands continuous use.

What stands out

• Long cutter life: rated for 500,000 cuts, reducing maintenance frequency.
• Wide media compatibility: handles paper, synthetic labels, and tags up to 108 mm wide and 0.25 mm thick.
• Automatic operation: printer-controlled cutting for seamless workflow integration.
• Safety-first design: enclosed blade mechanism protects users during operation.
• Field-installable: includes mounting hardware and installation guide for quick setup.

Technical details

• Cutter type: Guillotine
• Cutting method: Full cut
• Maximum cut width: 108 mm (4.25 inches)
• Minimum cut length: 20 mm
• Maximum media thickness: 0.25 mm
• Operating temperature: 5°C to 40°C (41°F to 104°F)
• Storage temperature: -20°C to 60°C (-4°F to 140°F)
• Operating humidity: 20-85% non-condensing
• Construction material: Metal alloy, durable plastic
• Certifications: CE, FCC

Our verdict

A dependable guillotine cutter that extends the versatility of TSC printers, delivering precise cuts and long-lasting performance for label-intensive operations.
