RUKO MGR-DIN357-M6x1,0mm Κρίκος με σπείρωμα

With a 12 mm eye inner diameter and a 35 mm overall length, this metric M6 eye bolt secures loads with reliable strength.

Overview

The RUKO GMBH MGR-DIN357-M6x1.0mm is a steel eye bolt manufactured to DIN 357 standards. Its metric coarse thread (M6 x 1.0 mm) and zinc-plated finish with blue passivation provide moderate corrosion resistance, making it suitable for securing, anchoring, and light lifting applications.

What stands out

• DIN 357 compliance ensures consistent dimensions and performance.
• Zinc-plated steel offers a balance of strength and corrosion resistance.
• Eye inner diameter of 12 mm accommodates a variety of hooks or ropes.
• Thread length of 18 mm allows secure engagement in tapped holes or nuts.

Technical details

• Product Type: Eye Bolt
• Standard: DIN 357
• Thread Type: Metric Coarse Thread
• Nominal Thread Diameter: M6
• Thread Pitch: 1.0 mm
• Material: Steel
• Surface Finish: Zinc-Plated (Blue Passivated)
• Eye Inner Diameter (d2): 12 mm
• Eye Outer Diameter (d3): 20 mm
• Collar Diameter (d4): 16 mm
• Collar Thickness (k): 6 mm
• Overall Length (L): 35 mm
• Thread Length (l1): 18 mm
• Head Form: Ring / Eye
• Drive Type: External Thread
• Colour: Silver
• Quantity per Pack: 1

Our verdict

A solid DIN-standard eye bolt for light-duty anchoring and securing tasks, with a corrosion-resistant zinc coating.
