Rittal VX Πλαίσιο σύνδεσης μπροστά για σύστημα ντουλαπιών VX25

The Rittal VX Baying Frame Front is a high-quality accessory designed for the VX25 enclosure system, enabling secure and stable side-by-side baying of enclosures. This front-mounted baying frame provides structural integrity and maintains the IP protection rating when used with appropriate baying seals. Manufactured from sheet steel with a dipcoat-primed and powder-coated surface finish in RAL 7035 light grey, it offers excellent corrosion resistance and durability. The symmetrical profile design allows for flexible baying configurations, making it an ideal solution for creating larger enclosure systems in industrial and IT environments.

Advantages

Ensures reliable and stable connection between VX25 enclosures. Easy screw-fastened installation with included assembly components. Maintains high protection category and corrosion resistance. Flexible baying options due to symmetrical profile design.

Suitable for

• Rittal VX25 enclosure systems requiring side-by-side baying
• Industrial control cabinets and IT infrastructure
• Applications needing extended enclosure capacity with maintained protection

Key specifications

• Product Type: Baying Frame
• Mounting Position: Front
• Material: Sheet steel
• Surface Finish: Dipcoat-primed, powder-coated
• Colour: RAL 7035 (Light Grey)
• Enclosure Height Compatibility: 2000 mm
• Scope of Supply: 1 baying frame, assembly components
• Unit of Sale: 1 piece

Recommendations

For optimal sealing and protection, use Rittal baying seals (sold separately) with this frame. Ensure enclosures are properly aligned before installation.
