PULS MiniLine ML50.100 τροφοδοτικό ράγας DIN 24V/DC 2,1A 50W

The PULS MiniLine ML50.100 stands out among DIN rail power supplies for its compact plastic housing and high efficiency of 89.5%, delivering 50W in a space-saving design. It accepts a wide AC input range of 85-264VAC, making it suitable for global use, and provides a stable 24VDC output with 2.1A current capacity.

Highlights

• 24VDC output, 2.1A, 50W
• Wide input range: 85-264VAC or 100-150VDC
• High efficiency: 89.5%
• DIN rail mountable (TS35/7.5 or TS35/15)
• Adjustable output voltage: 24-28VDC
• Overload, short-circuit, overvoltage, and over-temperature protection
• Operating temperature: -10°C to +70°C
• Low ripple and noise: <50mVpp
• Screw terminal connections
• MTBF >1,000,000 hours

In daily use

The ML50.100 is designed for industrial control panels and building automation. Its constant current limiting ensures reliable operation under overload conditions, with automatic recovery. The plastic housing provides electrical isolation, and the unit can be mounted on standard DIN rails without additional accessories.

Full specifications

• Output voltage: 24 VDC (adjustable 24-28 VDC)
• Output current: 2.1 A
• Output power: 50 W
• Input voltage AC: 85-264 VAC
• Input voltage DC: 100-150 VDC
• Efficiency: 89.5%
• Ripple and noise: <50 mVpp
• Hold-up time: >20 ms at 230VAC
• Overload protection: constant current, auto-recovery
• Short-circuit protection: constant current, auto-recovery
• Overvoltage protection: 29-33 VDC
• Over-temperature protection: yes
• Operating temperature: -10°C to +70°C
• Protection class: IP20
• Connection: screw terminals
• MTBF: >1,000,000 h (SN 29500)
• Housing material: plastic

Final note

The PULS MiniLine ML50.100 is a reliable and efficient power supply for demanding industrial applications, offering robust protection features and flexible mounting.
