Προσαρμογέας USB Type C σε υποδοχή HDMI/υποδοχή USB A/PD Equip 133461

The equip® USB Type C to HDMI adapter lets you connect a laptop or MacBook with a USB Type-C port to an HDMI display. The compact adapter combines a USB-C video output with an HDMI female port, a USB-A female port and USB Power Delivery (PD) support to enable simultaneous video output and power delivery to the connected laptop.

Advantages

The adapter supports USB 3.2 Gen 1 (3.1 Gen 1) on the Type-A port for high-speed data transfer and provides a single HDMI port for HD video output. Its small plastic housing and lightweight design (approximately 45 g) make it easy to carry and use for on-the-go presentations or at a workstation. PD functionality allows the laptop to receive power while the HDMI display is active, reducing the need for additional cables.

Suitable for

• Connecting a USB-C laptop or MacBook to an external HDMI monitor or TV
• Presentations, meetings and classroom use
• Streaming video or mirroring displays for work or entertainment
• Adding a USB-A port for peripherals when using a USB-C host

Key specifications

• Manufacturer: EQUIP
• Model / MPN: 133461
• EAN: 4015867203675
• Interfaces: USB Type-C (host), HDMI female, USB 3.2 Gen 1 Type-A female
• Features: USB Power Delivery (PD), HDMI video output
• Product colour: White
• Dimensions: 75 mm x 15 mm x 150 mm (approx.)
• Weight: 0.045 kg

How to use

Connect the adapter’s USB-C plug to the USB-C port on your laptop or MacBook. Plug an HDMI cable from the adapter’s HDMI female port to the HDMI input on your monitor or TV. If required, connect a USB-A device to the adapter’s USB-A port. To provide power to the laptop while outputting video, connect a USB-C PD charger to the host device or a PD-enabled port as applicable. Follow your computer’s display settings to select mirrored or extended display mode.

Recommendations

Use good-quality HDMI and USB-C cables rated for the required resolution and data speed. Ensure your laptop’s USB-C port supports video output (DisplayPort Alt Mode) and PD if you need simultaneous charging and display. Avoid excessive bending of the adapter and cables to prolong device life.
