MOES WCB-A5-TW-E1 Wi-Fi Tunable White LED Driver

Control tunable white LED strips with the MOES WCB-A5-TW-E1 Wi-Fi LED Driver. Install it in a cabinet, behind a TV, or along a ceiling cove, then adjust brightness and colour temperature from 2700K warm white to 6500K cool white using the Tuya Smart or Smart Life app. Voice commands via Amazon Alexa or Google Assistant add hands-free convenience for home or commercial lighting projects.

Key specifications

• Input: AC 100-240V, 50/60Hz
• Output: DC 12V-24V, max 5A
• Max power: 60W at 12V, 120W at 24V
• Wi-Fi 2.4GHz (IEEE 802.11 b/g/n)
• 2 channels: warm white + cold white
• Dimming range: 0-100%
• Colour temperature: 2700K-6500K
• Housing: PC V0 fire-retardant
• Protection: overload, short-circuit, over-temperature
• Operating temperature: -10°C to 40°C

Why choose it

This driver replaces a basic LED power supply with smart, app-controlled tunable white lighting. It supports both 12V and 24V LED strips, handles up to 120W, and includes essential protection circuits for reliable operation.

Ideal use cases

• Under-cabinet and cove lighting in kitchens or living rooms
• Accent lighting for retail displays or home theatres
• Bedroom or bathroom lighting with adjustable warmth
• DIY smart home projects using Tuya ecosystem devices

Good to know

The driver connects directly to a 2.4GHz Wi-Fi network and does not require a separate hub. It is compatible with the Tuya Smart and Smart Life apps, enabling scheduling, scenes, and remote control.
