MITON MT-P1280-S-B Κουτί Εξωτερικό ABS Γκρι IP65 IK07

The MITON MT-P1280-S-B is a robust surface-mounted electrical enclosure designed for indoor and outdoor applications. Manufactured from high-quality ABS (Acrylonitrile Butadiene Styrene), this enclosure offers excellent durability and resistance to impact and environmental conditions. With an IP65 rating, it provides complete protection against dust ingress and low-pressure water jets, making it suitable for demanding industrial environments. The IK07 impact resistance ensures protection against mechanical shocks. The opaque screw-on lid with four screws and a polyurethane gasket guarantees a secure and weatherproof seal. Internal mounting bosses allow for easy installation of DIN rails or mounting plates. This enclosure is ideal for junction boxes, distribution boards, and control enclosures.

Advantages

High-quality ABS material ensures long-lasting performance. IP65 and IK07 ratings provide excellent protection against dust, water, and impacts. The screw-on lid with gasket ensures a reliable seal. Internal mounting options offer flexibility for various components. Suitable for both indoor and outdoor use.

Suitable for

• Junction and connection boxes
• Distribution boards
• Control enclosures
• Electrical installations in industrial, commercial, and residential settings

Key specifications

• Enclosure Type: Surface-Mounted Electrical Enclosure
• Material: ABS (Acrylonitrile Butadiene Styrene)
• Colour: Grey (RAL 7035)
• Ingress Protection (IP) Rating: IP65
• Impact Resistance (IK) Rating: IK07
• Lid Type: Opaque, Screw-on
• Number of Lid Screws: 4
• Gasket Material: Polyurethane (PU)
• Operating Temperature Range: -25°C to +60°C
• Flammability Rating: UL94-HB
• UV Resistance: Yes
• Internal Mounting Options: Mounting bosses for DIN rail or mounting plate
• Application Environment: Indoor/Outdoor
• External Dimensions (L x W x H): 120 x 80 x 50 mm
• Internal Dimensions (L x W x H): Approx. 112 x 72 x 45 mm

Recommendations

For optimal installation, use appropriate cable glands and mounting accessories. Ensure the enclosure is securely fixed to a flat surface. This product is a reliable choice for protecting electrical connections in harsh environments.
