Μικρόφωνο Sennheiser TeamConnect Ceiling Medium TCC M-S-W

The Sennheiser TeamConnect Ceiling Medium TCC M‑S‑W is a ceiling microphone designed for medium-sized meeting rooms, lecture spaces and collaboration areas. With coverage up to 40 m² and a white, low-profile design, it integrates into existing ceilings and connects via RJ-45 for easy system integration.

Advantages

The microphone uses patented automatic dynamic beamforming and an array of 15 SMD electret condenser capsules made in Germany to capture clear speech from multiple directions. Power over Ethernet (PoE) simplifies installation by carrying power and data over a single cable. The unit is certified for Microsoft Teams, Zoom, DingTalk and Tencent, supports camera control via talker position data, and includes network security features such as IEEE 802.1x and TLS 1.2.

Suitable for

• Medium-sized meeting rooms
• Lecture halls and classrooms
• Collaboration and huddle spaces
• Conference calls and hybrid meetings

Key specifications

• Coverage area: up to 40 m²
• Microphone type: ceiling array with 15 SMD electret condenser capsules
• Beamforming: patented automatic dynamic beamforming
• Connectivity: RJ-45 (Ethernet), PoE
• Certifications: Microsoft Teams, Zoom, DingTalk, Tencent
• Security: IEEE 802.1x, TLS 1.2
• Camera control: via talker position data
• Color/finish: white, low-profile design
• Manufacturer part number (MPN): 700294
• EAN: 4044155278033

How to use

Install the TeamConnect Ceiling Medium into the ceiling following the room layout to ensure optimal coverage of up to 40 m². Connect the device to the network using an RJ-45 Ethernet cable and provide power via PoE. Configure the microphone in the audio or conferencing system, select the appropriate certification profile if required (e.g., Microsoft Teams or Zoom), and enable camera control features in compatible systems to use talker position data for automatic camera steering.

Recommendations

Place the microphone centrally in the room when possible and avoid installing it directly above noisy equipment. For best speech intelligibility, verify network and PoE provisioning beforehand and perform calibration or system checks with typical room occupancy and seating arrangements.
