Merten μηχανισμός διακόπτη 1-πολικός 10A 250V MEG3050-0000

In modern electrical installations, controlling lighting or other loads with a simple push of a button requires a reliable, safe switching mechanism. The Merten Push-Button Insert MEG3050-0000 provides exactly that: a robust 1-pole, 10 A, 250 V AC momentary-contact insert designed for flush mounting in standard wall boxes. It serves as the functional core behind compatible Merten push-button covers, enabling convenient control of lights, stairwell timers, or other switching applications.

Who is it for

This insert is intended for electricians, installers, and technically skilled DIY enthusiasts who are building or renovating electrical installations using the Merten System M, System Design, or System Basis ranges. It is ideal for anyone seeking a durable, VDE-certified push-button mechanism that integrates seamlessly with Merten frames and rockers.

Main features

• 1-pole momentary contact (normally open) for push-button switching
• Rated current 10 A and rated voltage 250 V AC for versatile use
• Screw terminals ensure secure and maintenance-free connections
• Flush-mounted design fits standard flush boxes
• Halogen-free thermoplastic housing for enhanced safety
• Compatible with Merten System M, System Design, and System Basis covers
• VDE certified for compliance with German and European safety standards

Specifications

• Product type: Push-button insert
• Number of poles: 1
• Rated current: 10 A
• Rated voltage: 250 V AC
• Switching function: Momentary contact (normally open)
• Connection type: Screw terminals
• Number of terminals: 2
• Mounting type: Flush-mounted
• Material: Thermoplastic, halogen-free
• Degree of protection: IP20 (insert only)
• Operating temperature: -5 to +40 °C
• Storage temperature: -25 to +55 °C
• Certification: VDE
• Compatibility: Merten System M, System Design, System Basis

Tips

Always disconnect the power supply before installation. Choose a compatible Merten push-button cover or rocker from the same system range to complete the assembly. For outdoor or damp locations, use an appropriate surface-mounted housing or additional protection, as the insert itself is rated IP20.
