MEAN WELL ELG-150-36A-3Y LED Driver 150 W 36 V DC 4,17 A IP65 dimmable

LED driver delivering 150 W at 36 V DC with 4.17 A output, built for demanding indoor and outdoor lighting installations. Its 3-in-1 dimming (0-10 V, PWM, resistance) allows flexible brightness control.

Advantages

High efficiency of 91% reduces energy consumption and heat. Active PFC ensures stable operation across a wide 100-305 V AC input range. The IP65 aluminum housing withstands dust and water jets, making it suitable for harsh environments.

Suitable for

• LED street lighting
• Floodlights
• High-bay fixtures
• Outdoor signage

Key specifications

• Output: 150 W, 36 V DC, 4.17 A
• Input: 100-305 V AC
• Dimming: 3-in-1 (0-10 V, PWM, resistance)
• IP rating: IP65
• Protections: short circuit, over current, over voltage, over temperature
• Operating case temperature: -40 to +90 °C

Recommendations

For reliable LED lighting in outdoor or industrial settings, this driver offers robust performance and flexible control.
