MEAN WELL APV-35-24 36W 24V LED driver σταθερής τάσης, είσοδος 90-264V AC, παθητική ψύξη, Λευκό

The MEAN WELL APV-35-24 is a 36W constant voltage LED driver that delivers a stable 24V DC output with an efficiency of 84%. Its wide 90-264V AC input range and passive free-air convection cooling make it a dependable power solution for a variety of LED lighting installations.

Advantages

This driver operates across a broad input voltage range of 90-264V AC (127-370V DC), ensuring compatibility with mains supplies worldwide. The passive cooling design eliminates fan noise and reduces maintenance, while the built-in protections against short circuit, overload, and over voltage safeguard both the driver and connected LEDs. The compact plastic housing is IP42 rated, providing protection against solid objects and dripping water. With an operating temperature range of -30°C to 70°C, it performs reliably in harsh environments. Certified to UL, cUL, TUV, and CE standards, it meets rigorous safety and quality requirements.

Suitable for

• LED strip lighting and modules requiring 24V DC
• Architectural and decorative lighting
• Signage and channel letter illumination
• Industrial and commercial lighting fixtures
• Indoor and outdoor applications with appropriate enclosure

Key specifications

• Output power: 36 W
• Output voltage: 24 V DC
• Output current: 1.5 A
• Input voltage: 90-264 V AC (127-370 V DC)
• Input frequency: 47-63 Hz
• Efficiency: 84%
• Cooling: Passive (free air convection)
• Operating temperature: -30 to 70 °C
• Protections: Short circuit, overload, over voltage
• IP rating: IP42
• Housing material: Plastic
• Colour: White
• Certifications: UL, cUL, TUV, CE
• Dimensions (W x H x D): 84 x 30 x 57 mm
• Weight: 0.13 kg

Recommendations

For optimal performance, ensure adequate ventilation around the driver and do not exceed the rated load. When used in outdoor or damp locations, install the driver in a suitable enclosure to maintain the IP42 protection level. Always verify that the total wattage of connected LEDs does not exceed 36W to prevent overload.
