Klauke 170/W Μονωμένο ακροχιτώνιο 0,75 mm² γκρι

The Klauke 170/W is a high-quality insulated wire end sleeve designed for reliable and secure termination of stranded conductors. Manufactured from tin-plated electrolytic copper, this sleeve ensures excellent conductivity and corrosion resistance. The funnel-shaped wire entry facilitates easy insertion of conductors, while the grey insulation provides clear identification for 0.75 mm² cross-sections. Compliant with DIN 46228 Part 4, this sleeve is suitable for a wide range of electrical applications.

Advantages

This wire end sleeve offers several benefits: tin-plated copper construction for optimal electrical performance and long-term reliability; funnel-shaped entry for quick and easy wire insertion; halogen-free and RoHS compliant for environmental safety; wide temperature range from -40 °C to +105 °C; and voltage rating of 300 V for versatile use.

Suitable for

• Control cabinets and switchgear
• Electrical installations and wiring
• Automation and industrial applications
• Termination of stranded wires in terminal blocks

Key specifications

• Wire Cross-Section: 0.75 mm²
• Insulation Type: Insulated
• Insulation Color: Grey
• Material: Electrolytic Copper, tin-plated
• Sleeve Length (Metal Part): 12 mm
• Total Length: 18 mm
• Inner Diameter (Metal Sleeve): 1.3 mm
• Flange Diameter: 2.8 mm
• Outer Diameter (Insulation): 2.5 mm
• Wire Entry: Funnel-shaped
• Standard Compliance: DIN 46228 Part 4
• Temperature Resistance: -40 °C to +105 °C
• Voltage Rating: 300 V
• Halogen-free: Yes
• RoHS Compliant: Yes
• Packaging Unit: 1000 pieces
• Product Type: Single Wire End Sleeve
• Series: Klauke 170/W

Recommendations

For best results, use with a suitable crimping tool designed for insulated wire end sleeves. Ensure the conductor is stripped to the correct length before insertion. Store in a dry environment to maintain performance.
