JUNG Διακόπτης Κλειδιού 10AX 250V 1-πολικός 804.18W Λευκό Αλπικό

Controlling access to lighting, motors, or security circuits often requires a switch that can be locked to prevent unauthorized operation. The JUNG 804.18W key switch provides a 1-pole latching contact rated for 10AX at 250V AC, operated by a key that can be removed in both the on and off positions. This allows the circuit to be secured in either state, making it suitable for public buildings, industrial facilities, or private homes where only authorized personnel should change the switching state.

Who is it for

Electricians, facility managers, and homeowners who need a flush-mounted key-operated switch for lighting, motor control, or access systems. It is compatible with JUNG cover plates and frames from the AS, A, CD, and LS ranges, allowing integration into existing installations.

Main features

• 1-pole changeover contact, latching function
• Rated current 10AX, rated voltage 250V AC
• Key removable in both positions (0 and 1)
• Flush-mounted installation with screw terminals
• Thermoplastic, shatterproof housing in Alpine White
• Supplied with 2 keys

Specifications

• Switch type: Key switch
• Number of poles: 1
• Switching function: Latching
• Rated current: 10 AX
• Rated voltage: 250 V AC
• Contact configuration: 1-pole changeover
• Mounting type: Flush-mounted
• Connection type: Screw terminals
• Material: Thermoplastic, shatterproof
• Colour: Alpine White
• Protection class: IP20
• Number of keys supplied: 2
• Key removal position: In both positions (0 and 1)
• Operating temperature range: -5 to +40 °C
• Certification: VDE

Tips

For a complete installation, combine this insert with a suitable JUNG cover plate and frame from the AS, A, CD, or LS series. The key can be removed in either position, so you can lock the circuit on or off as needed.
