HP Power Board & Cable - Εσωτερική πλακέτα διανομής ρεύματος

The HP Power Board & Cable (767346-001) is an internal power splitter board designed for distributing power from a single SATA power source to multiple devices. It features one SATA 15-pin male input and three outputs: two SATA 15-pin female and one Molex 4-pin female, supporting 5V and 12V voltages. Ideal for expanding power connections inside a PC, this board is compatible with SATA HDDs/SSDs, optical drives, and fans.

Advantages

This power splitter board simplifies cable management by consolidating power distribution from one input to three outputs. It supports both 5V and 12V, making it versatile for various internal components. The plug-and-play design requires no additional drivers or software, ensuring easy installation.

Suitable for

• Desktop PC builds requiring additional SATA power connections
• Upgrading or adding SATA HDDs/SSDs, optical drives, or fans
• Internal power distribution in servers or workstations

Key specifications

• Product Type: Power Splitter Board
• Input Connector: 1 x SATA 15-pin Male
• Output Connector 1: 2 x SATA 15-pin Female
• Output Connector 2: 1 x Molex 4-pin Female
• Number of Outputs: 3
• Supported Voltages: 5V, 12V
• Material: PCB, Plastic Connectors
• Color: Green (PCB), Black (Connectors)
• Compliance: RoHS

Recommendations

Ensure your power supply has an available SATA 15-pin male connector. This board is power-only and does not support data transfer. Verify compatibility with your device's power requirements before installation.
