HP Hvps C35Hvpsm/D 24V 21.6V 26.4V Max2k Τροφοδοτικό DC

The HP Hvps C35Hvpsm/D is a high-performance enclosed industrial DC power supply delivering a nominal 24V output with an adjustable range of 21.6V to 26.4V DC. With a maximum output power of 2000W (2kW) and a current capacity of 83.3A, this unit is designed for demanding applications such as industrial automation, test equipment, LED lighting, and control systems. Its forced air cooling ensures reliable operation even under heavy loads.

Advantages

This power supply offers high efficiency (>90%), comprehensive protection features (overload, overvoltage, short circuit, overtemperature), and a wide operating temperature range from -20°C to +70°C. The remote ON/OFF and remote sense control interfaces provide flexibility for integration into complex systems.

Suitable for

• Industrial automation and control systems
• Test and measurement equipment
• LED lighting installations
• Any application requiring a stable 24V DC power source up to 2kW

Key specifications

• Input Voltage: 200-240V AC, 50/60 Hz
• Output Voltage: 24V DC nominal (adjustable 21.6-26.4V DC)
• Maximum Output Power: 2000W (2kW)
• Maximum Output Current: 83.3A
• Efficiency: >90%
• Cooling: Forced air (fan-cooled)
• Protection: Overload, Overvoltage, Short Circuit, Overtemperature
• Form Factor: Enclosed industrial
• Input/Output Connector: Terminal block
• Operating Temperature: -20°C to +70°C
• Certifications: CE, RoHS
• Control Interface: Remote ON/OFF, Remote Sense

Recommendations

For optimal performance, ensure adequate ventilation around the unit and use appropriately rated wiring for the high current output. This power supply is ideal for replacing or upgrading existing 24V systems requiring high power density.
