Hellermann Tyton 712-00503 μονωτική ταινία PVC, μαύρο, 19 mm x 20 m

PVC electrical insulating tape in black, 19 mm wide and 20 m long. Provides reliable insulation, bundling, and marking of electrical cables and wires. The rubber-based adhesive ensures strong adhesion to steel and backing, while the tape remains flexible and easy to apply. Suitable for indoor and outdoor use, with UV resistance and self-extinguishing properties.

Advantages

Flame retardant and self-extinguishing for added safety. Resistant to ultraviolet light, making it suitable for outdoor applications. Good dielectric strength of 9 kV for effective insulation. Flexible and conformable, ideal for wrapping irregular shapes.

Suitable for

• Insulating electrical connections and splices
• Bundling and harnessing wires and cables
• Marking and color-coding electrical circuits
• Repairing damaged cable insulation

Key specifications

• Material: PVC (Polyvinyl Chloride)
• Adhesive Type: Rubber-based
• Width: 19 mm
• Length: 20 m
• Thickness: 0.15 mm
• Dielectric Strength: 9 kV
• Temperature Resistance: -10 °C to +90 °C
• Tensile Strength: 20 N/10mm
• Elongation at Break: 180%
• Adhesion to Steel: 1.8 N/10mm
• Adhesion to Backing: 1.8 N/10mm
• Flame Retardant: Yes (Self-extinguishing)
• UV Resistance: Yes
• Core Diameter: 38 mm

Recommendations

For best results, apply to clean, dry surfaces at temperatures above 0 °C. Store in a cool, dry place away from direct sunlight.
