HellermannTyton Helagaine HEGWS πλεκτός σωλήνας, 9mm, μαύρο, 25m 339-01909

In control cabinets and machinery, cable bundles need protection from abrasion and heat. The HellermannTyton Helagaine HEGWS braided sleeving, 9 mm nominal diameter, black, 25 m length, is used by panel builders and maintenance technicians to bundle and shield wires, cables, and hoses. Made from polyester (PET), it offers high flexibility and abrasion resistance, with an operating temperature range of -50 °C to +150 °C and a melting point of +250 °C. The sleeving is halogen-free and UV resistant, with a flammability rating of UL94 V2 and good chemical resistance. It expands from 6 mm to 12 mm to fit over connectors and irregular bundles.

Key specifications

• Material: Polyester (PET)
• Colour: Black
• Nominal diameter: 9 mm
• Expandable range: 6 mm to 12 mm
• Length: 25 m
• Operating temperature: -50 °C to +150 °C
• Melting point: +250 °C
• Flammability: UL94 V2
• Halogen-free: Yes
• UV resistant: Yes
• Abrasion resistance: High
• Chemical resistance: Good
• Flexibility: High

Why choose it

This braided sleeving provides reliable mechanical protection and neat bundling in demanding environments. Its wide temperature range and halogen-free composition make it suitable for applications where safety and durability are critical.

Ideal use cases

• Bundling cables in control panels and switchgear
• Protecting wire harnesses in automotive and industrial machinery
• Organizing hoses and cables in robotics and automation
• Adding abrasion resistance to exposed wiring

Good to know

The sleeving is supplied in a 25 m roll and can be cut to length as needed. Its expandable design accommodates varying bundle diameters, simplifying installation over connectors.
