HellermannTyton 300-30160 θερμοσυστελλόμενο μακαρόνι 3:1, 3 mm, μαύρο, 10 m

Heat shrink tubing with 3:1 shrink ratio, supplied internal diameter 3 mm, recovered internal diameter 1.5 mm, black, 10 m length. Made of cross-linked polyolefin, it provides electrical insulation, mechanical protection, bundling, and strain relief.

Advantages

Cross-linked polyolefin material offers good chemical resistance and UV resistance for black tubing. The 3:1 shrink ratio allows coverage of irregular shapes and connectors. Dielectric strength >20 kV/mm provides reliable electrical insulation. Operating temperature range from -55°C to +125°C suits harsh environments. UL224 VW-1 flammability rating ensures self-extinguishing properties.

Suitable for

• Electrical insulation of wires and connections
• Mechanical protection against abrasion and impact
• Bundling and organizing cables
• Strain relief for connectors and terminations

Key specifications

• Material: Cross-linked polyolefin
• Shrink ratio: 3:1
• Supplied internal diameter: 3 mm
• Recovered internal diameter: 1.5 mm
• Length: 10 m
• Colour: Black
• Operating temperature range: -55°C to +125°C
• Minimum shrink temperature: +90°C
• Dielectric strength: >20 kV/mm
• Flammability rating: UL224 VW-1
• Tensile strength: 10.4 MPa
• Elongation at break: 200%
• Recovered wall thickness: 0.45 mm
• Chemical resistance: Good against common fluids and solvents
• UV resistance: Good (for black)
• Halogen-free: No
• Approvals: UL224, RoHS compliant

Recommendations

Use a heat gun set to at least +90°C to shrink the tubing evenly. For best results, select tubing with supplied diameter slightly larger than the object to be covered, ensuring a snug fit after recovery.
