HEINRICH KOPP Πρίζα χωνευτή universal, χωρίς βίδες, πολικό λευκό 308402001

Installing a socket outlet can be time-consuming when you have to deal with screw terminals, especially in tight flush-mounted boxes. The HEINRICH KOPP 308402001 solves this with push-in terminals that accept solid or stranded conductors from 1.5 to 2.5 mm², making wiring fast and tool-free. Its universal socket accepts both Schuko and standard European plugs, so it works with a wide range of devices.

Who is it for

Electricians and DIY installers who need a reliable, screwless flush-mounted socket for residential or commercial wiring. It is ideal for new installations or replacements where speed and secure connections matter.

Main features

• Universal socket type: compatible with Schuko and standard plugs
• Screwless push-in terminals for quick, secure wiring
• Flush-mounted design for a clean, integrated look
• Polar white (RAL 9010) glossy finish blends with standard switch ranges
• Integrated child protection for added safety
• Halogen-free thermoplastic housing

Specifications

• Socket type: Universal (Schuko compatible)
• Mounting type: Flush-mounted
• Connection type: Push-in terminals (screwless)
• Rated voltage: 250 V AC
• Rated current: 16 A
• Frequency: 50/60 Hz
• Colour: Polar white (RAL 9010)
• Material: Thermoplastic (PC/ABS)
• Surface finish: Glossy
• Protection class: IP20
• Child protection: Yes
• Halogen-free: Yes
• Number of sockets: 1
• Number of modules: 1
• Installation depth: 32 mm
• Terminal capacity: 1.5 - 2.5 mm²
• Impact resistance: IK05

Tips

For a consistent look, pair this socket with other HEINRICH KOPP flush-mounted inserts in polar white. The screwless terminals reduce installation time, but ensure conductors are stripped to the correct length for a reliable connection.
