Hager WNA140B Μηχανισμός πρίζας Schuko, πολικό λευκό

Rated at 16 A and 250 V AC, the Hager WNA140B Schuko socket outlet insert delivers reliable power in a compact, flush-mounted design. Its polar white (RAL 9010) finish and matt surface blend seamlessly into modern interiors.

Overview

Part of the Hager WNA series, this single socket outlet insert is built from halogen-free thermoplastic for safety and durability. Screw terminals accept rigid conductors up to 2.5 mm², ensuring a secure connection. The insert includes a central plate and is designed for flush mounting with a depth of approximately 32 mm.

What stands out

• Schuko (Type F) socket with earth contact
• Halogen-free thermoplastic construction
• Polar white (RAL 9010) matt finish
• Flush-mounted design with central plate included

Technical details

• Socket type: Schuko (Type F)
• Rated current: 16 A
• Rated voltage: 250 V AC
• Colour: Polar white (RAL 9010)
• Connection type: Screw terminals
• Mounting type: Flush-mounted
• Material: Thermoplastic
• Halogen-free: Yes
• Protection degree: IP20
• Number of sockets: 1
• Child protection: No (standard)
• Design line: Hager WNA
• Terminal capacity: Up to 2.5 mm² (rigid conductors)
• Mounting depth: Approx. 32 mm
• Earth contact: Yes
• Surface finish: Matt
• Central plate included: Yes
• Frame included: No

Our verdict

A straightforward, halogen-free Schuko socket insert that meets standard installation needs with a clean polar white look.
