EXSYS EX-12001-2 προσαρμογέας PCIe x2 Low-Profile USB 3.2 Gen 2x2

Add a 20Gbps USB-C port to your desktop PC with this low-profile PCIe adapter. Unlike typical USB 3.0 cards, the EX-12001-2 uses the USB 3.2 Gen 2x2 standard, doubling throughput for external SSDs and high-speed peripherals.

Highlights

• PCI Express 3.0 x2 host interface, compatible with x4, x8, and x16 slots
• One USB-C female port with up to 15W power delivery (5V/3A)
• ASMedia ASM3242 chipset for reliable performance
• Includes both low-profile and standard height brackets
• Plug & Play installation with driver support for Windows and Linux

In daily use

Install the card in a free PCIe slot, connect the SATA power cable for full power delivery, and you're ready to connect USB-C devices. Backward compatibility ensures existing USB 3.1 and USB 2.0 peripherals work at their native speeds.

Full specifications

• Host interface: PCI Express 3.0 x2
• Output interface: USB 3.2 Gen 2x2 Type-C
• Data transfer rate (max): 20 Gbps
• Chipset: ASMedia ASM3242
• Internal power connector: 1x SATA 15-pin
• Form factor: Low-profile PCIe card
• USB-C ports: 1
• Power delivery: Up to 5V/3A (15W)
• Operating systems: Windows 7/8/10/11 (32/64-bit), Linux Kernel 4.x and above
• Compliance: USB-IF Certified

Final note

A compact solution for adding modern USB-C connectivity to any desktop system, with the speed to handle demanding data transfers.
