EWIMAR BOX-2 Αδιάβροχο κουτί διακλάδωσης IP66 γκρι

The EWIMAR BOX-2 is a high-quality waterproof junction box designed for reliable electrical connections in demanding environments. With an IP66 protection rating and IK07 impact resistance, it offers excellent protection against dust, water jets, and mechanical impacts. Made from durable polypropylene (PP) with a TPE gasket, this box is suitable for both indoor and outdoor use. It features 7 pre-formed knockouts for cable entries (M20/M25) and is secured with 4 stainless steel screws. The box is halogen-free and UV-resistant, ensuring long-lasting performance.

Advantages

Robust IP66 and IK07 protection for harsh conditions. Halogen-free and UV-resistant materials ensure safety and durability. Easy installation with pre-formed knockouts and stainless steel fasteners. Versatile for a wide range of applications.

Suitable for

• Electrical junction and connection points in industrial, commercial, and residential settings
• Outdoor installations such as gardens, terraces, and building exteriors
• Use in dusty or wet environments requiring high ingress protection

Key specifications

• Protection Rating: IP66
• Impact Protection: IK07
• Material: Polypropylene (PP)
• Colour: Grey (RAL 7035)
• Mounting Type: Surface-mounted
• Number of Cable Entries: 7 (pre-formed knockouts)
• Cable Entry Diameter: M20 / M25
• Operating Temperature: -25°C to +60°C
• Rated Voltage: 400V AC
• Rated Current: 16A
• Max Wire Cross-section: 2.5 mm²
• Lid Fastening: 4x Stainless Steel Screws
• Gasket Material: TPE
• Halogen-free: Yes
• UV Resistance: Yes
• Internal Depth: Approx. 35 mm
• Terminal Block: Not included (empty box)

Recommendations

For optimal performance, use appropriate cable glands (not included) to maintain IP66 rating. Ensure the gasket is properly seated before closing the lid.
