Epson SELECTOR,UNIT,LL,ESL,ASP παλιό: 1674406

Manage up to 2,000 electronic shelf labels from a single access point with the Epson SELECTOR UNIT LL ESL ASP. This white, wall-mountable unit provides reliable 2.4 GHz RF communication across a 15-metre radius, ensuring your entire retail floor stays updated in real time.

Overview

The Epson SELECTOR UNIT LL ESL ASP is a dedicated access point for Epson's Electronic Shelf Label (ESL) system. It bridges your network and ESL tags, enabling instant price and information updates. With both Ethernet and PoE support, installation is flexible and cost-effective.

What stands out

• Supports up to 2,000 ESLs for large-scale deployments
• Proprietary 2.4 GHz RF with AES 128-bit encryption for secure communication
• Power over Ethernet (IEEE 802.3af) eliminates the need for separate power cabling
• Simple wall, ceiling, or desktop mounting options
• LED indicators for power, status, and network at a glance

Technical details

• Network interface: 1 x 10/100Base-TX Ethernet (RJ-45)
• Coverage: Up to 15 m radius (approx. 700 sq m)
• Power: DC 5V via AC adapter or PoE 802.3af
• Operating temperature: 0°C to 40°C
• Operating humidity: 20% to 80% RH non-condensing
• Management: Epson ESL Manager software
• Certifications: CE, FCC, RoHS
• Housing: White plastic, internal antenna
• Power consumption: approx. 3 W
• Firmware: field upgradable

Our verdict

A robust and secure access point that scales with your retail needs, offering easy deployment and centralised control for thousands of ESLs.
