Επίπεδο καλώδιο ACT modular 6 αγωγών TD606W λευκό 100 m

Flat cable ACT Modular 6 conductors TD606W in white on a 100 m drum. This modular flatcable contains six AWG26 conductors (each conductor made of 7x0.16 mm strands) and is intended for wiring applications where a low-profile, flexible cable is required. The white finish makes it suitable for visible installations and for integration with light-coloured surfaces.

Advantages

The cable combines a flat, space-saving design with flexible stranded conductors for improved bendability. Its 100 m drum format is convenient for longer runs and reduces the need for jointing. The white outer colour supports discreet installation in residential and commercial environments. Conductors specified as AWG26 (7x0.16 mm) provide consistent electrical continuity for signal and low-current wiring.

Suitable for

• Telephone and low-voltage signal wiring
• Interconnects in security and alarm systems
• Internal wiring of equipment and cabinets
• Flat routing along skirting boards and behind panels

Key specifications

• Brand: ACT
• Model / MPN: TD606W
• Conductors: 6
• Conductor construction: 7 x 0.16 mm stranded (Litze)
• AWG size: AWG26
• Colour: White
• Length: 100 m (drum)

How to use

Unwind required length from the 100 m drum and cut with appropriate cable shears. Strip individual conductor insulation carefully to avoid nicking the strands. Route the flat cable along the desired path, using clips or adhesive channels to secure it in place. Terminate conductors to the appropriate connectors, blocks, or solder points according to the installation's wiring scheme and local electrical standards.

Recommendations

Store the drum in a dry, moderate-temperature environment. Avoid sharp bends with radii smaller than what the conductor construction permits, and do not subject the cable to excessive tensile stress when pulling through conduits or channels.
